Metal Structure Resonance

View Count: 104 Publication Time: November 11, 2024

Metal materials possess the advantages of high structural strength, a light and thin appearance, and a beautiful and fashionable look. They have been widely used in the shell design of current electronic terminal products.



The metal components of electronic product casings can achieve excellent resonance characteristics in the operating frequency band of video modules through special shape design, slit design, and connection auxiliary design, becoming high-performance and aesthetically pleasing radiation antennas.



Currently, most mobile phones, tablets, and even high-end electronic watches on the market have adopted this type of metal structural component for antenna design.



Amphenol has extensive experience in designing antennas using metal structures, ranging from built-in stamping antennas to metal strip antennas, from metal ring mobile phone antennas to laptop antennas, and even including metal flat antenna arrays.



At the same time, Amphenol also provides a series of complex antenna modules for metal resonant antennas, from simple connection feeding to integrated switches and sensors.



The application types of metal structure antenna products also cover consumer electronics, small indoor base stations, and large outdoor base stations. This type of structure has become an important component of modern antennas.
